Victron Orion 24/12-30 DC-DC Converter IP20A

• Input Voltage range: 18-35V
• Output Voltage: Adjustable 10-15V. F Set 13.2V
• Efficiency: 96%
• Continuous output current: 30A
• Max Output current: 40A
• Connections: Double Faston tabs (6.3mm)
• Dimensions: 65 x 88 x 160mm
• Weight: 0.7Kg

Remote on-off connector - The remote on-off eliminates the need for a high current switch in the input wiring. The remote on-off can be operated with a low power switch or by the engine run/stop switch (see manual).

All models with adjustable output can also be used as a battery charger - For example to charge a 12 Volt starter or accessory battery in an otherwise 24V system.

All models with adjustable output can be paralleled to increase output current - Up to five units can be connected in parallel.

Easy to install - Delivery includes four Insulated Fastons Female Crimp 6.3mm (eight Fastons in case of the Orion 24/12-40).
